Basic parameters

Product Model: PA01
Compatible Receiver: FTr16s, TMr and other AFHDS 3 protocol receivers ; PR01, PR02 and other ELRS receivers
Compatible RC Model: Racing drone, fixed-wing, glider, helicopter, car, boat, robot, etc.
Number of Channels: 18-channel is for Internal RF, and 32-channel is for External RF
RF: 2.4GHz ISM
Maximum Power: < 20dBm (e.i.r.p.) （EU）
RF Protocol: AFHDS 3/ELRS
Resolution: 4096
Data Connector: USB Type-C, 3.5mm Audio Jack, 3.5mm Trainer Connector(DSC)
Low Voltage Alarm: <7.2V
Antenna: Single antenna (external folding antenna)
Input Power: 7.4V 2*18650 LiPo
Display: 2.4 inch 240*320 full dot color non-touch IPS screen
Firmware Update: Supported
Temperature Range: -10℃ ~ +60℃
Humidity Range: 20% ~ 95%
Color: Black translucent
Dimensions: 174.9*131.4*67.5mm
Weight Transmitter weight: 343g (without battery);
Charging base weight: 67g (without battery)
Charging Jack: Yes (USB Type-C Port)
Certifications CE, FCC ID: 2A2UNPA010
